1. The diagnostic card is mainly used for computer motherboard.The four-layer PCB designed makes the signal more stable and can work for a time in harsh environment. 2. The four-layer PCB designed makes the signal more stable and can work for a time in harsh environment. 3. Tantalum capacitor is adopted to provide more stable and reliable power supply for the whole product. 4. In the layout is more perfect, more convenient to operate. 5. Made of high quality electronic components, stable and reliable performance. Specification: Item Type: Debug Card Material: PCB Color: Yellow Instructions for desktop four-in-one diagnostic card: I. Know the LPC interface of various brands of motherboards and the 1st pin direction of the interface. The interface picture can be viewed at the description of the desktop 4-in-1 diagnostic card purchased or the interface picture below. (Figures 1 and 2) 2. The four-in-one diagnostic card for the desktop is aimed at the 1st pin of the motherboard's LPC interface, as shown in the figure: Desktop 4-in-1 diagnostic card LPC interface introduction, in order to properly place the desktop 4-in-1 diagnostic card in the motherboard, the desktop 4-in-1 diagnostic card LPC interface and motherboard LPC interface have two starting points, the triangular indicates Pin 1 (Figures 3 and 4) 3. Note that the desktop four-in-one diagnostic card interface and the motherboard LPC interface are incorrect. It can be used. The desktop four-in-one diagnostic card can be pointed at the 1st pin of the motherboard's LPC interface. The motherboard's LPC interface has more or fewer pins. Leave him alone. 4. Many customers have questions about understanding the motherboard   running interface. Why does PCI-E not support all brands of motherboards? Assuming that PCI-E can support all brands of motherboards, then there is no need for LPC to run the . The motherboard's LPC interface is used to run the  , so customers do not need to search and find if there is a PCI-E universal card. Desktop 4 in 1 The diagnostic card is already better, please rest assured. The PCI-E slot   running is a for Gigabyte solution. Just for Gigabyte motherboards have the BIOS   sent to the PCI-E slot. Other brands send the BIOS   to the LPC header, and some send it to the PCI slot. for Gigabyte motherboard   running interface has PCI and PCI-E. A few use LPC. Some PCI can run  , then PCI-E will not run . Conversely, if there is no PCI slot, then PCI-E will run . Other brands use PCI and LPC interfaces to run . Some PCI can run , so LPC will not run . Conversely, if there is no PCI slot, then LPC will run . Each motherboard has an interface that can run , and interfaces that have BIOS can run . Interfaces that do not have a BIOS   are definitely not able to run . In short, each motherboard has an interface that can run . 5. Display 00, please replace the interface test, replace the LPC without a PCI slot, PCI-E does not run the   to replace the PCI, each motherboard has just one interface can run the  , display 00 users switch the interface test. 6.Desktop four-in-one diagnostic card Full view (Figure 5) Package List: 1 x Diagnosis Card 1 x Instruction
