1. Printer Control: For MKS Robin uses a 32 bit high speed ARM chip as the main control chip, equipped with a TFT43 touch screen, which has a simple operation interface and high sensitivity. Firmware can be upgraded through memory card, and user interface can be customized.
2. Easy Operation: External WiFi modules can be connected for the remote model printing. It also provides mobile APP of for and for OS X systems in both Chinese and English. The shutdown function can be realized by cooperating with the shutdown module.
3. Stable Working: The flexible motor drive mode can support 4988 8825 and various direct plug in drives, and support other external drives to meet your requirements for various drives.
4. Configuration: The interface of power on and all buttons can be designed by yourself. Up to 15 custom buttons can be supported.
5. Little Heat: Special power supply chip is adopted to support 12V-24V power input. It can accept 24V input. Under the same system power, the hot bed current can be reduced to 1/4. High quality MOSFET tubes are used for better heat dissipation.
6. Other Function: Support breakpoint continuous typing function, power off saving function, and material break detection function.
Specification:
Item Type: 3D Printer Control Board
Material: PCB
Input Voltage: 12-24V
Input Current: 5A-15A
Temperature Sensor Interface: NTC100K, 31855
Support Print File Format: G .
Recommended Software: For Cura, for Simplify3d, for Frontinterface, for RPetier Host.
Firmware Update: Storage card update
Microprocessor: STM32
Motor Driver: 4988 8825 8729 and other drives and external drives.
Color Touch Screen: For MKS Robin TFT43
Support Machine Structure: For XYZ, for , for kossel, for corexy.
Package List:
1 x
3D Printer Control Board1 x Touch Screen
1 x PCC Pin Header
1 x USB Cable
Note:
1. The motherboard default firmware is for robin35 screen. If you get the for robin43 screen, you need to the firmware yourself.
2. If the for robin43 screen does not support screen modification of machine parameters, the machine parameters can be modified in the txt file.
